Notify me when its in stockDOBOT MG400 4-Axis Robotic Arm
DOBOT MG400 is a lightweight, space-saving desktop robotic arm suitable for various production needs. It is flexible in deployment and easy to use, making it perfect for small-space applications. The MG400 4-axis robotic arm is a good choice for automatic bench scenarios in narrow workspaces that require rapid deployment and replacement.
DOBOT MG400 is an ultra-compact desktop robotic arm, with the footprint of the body base being just slightly larger than A4 paper. It is flexible and easy to use, and safe for collaboration. It is designed to meet the demand for automatic production of small batches. With a maximum payload of 750g and an arm length of 440mm, it fully meets the performance requirements of lightweight desktop applications, drag teaching, collision detection, and other human-machine collaboration features. The MG400 is sufficient to truly meet the rapid deployment application of the production line and is a cost-effective option for automatic and intelligent production.
Three programming methods - reproduction, graphical programming, and Lua script programming - are suitable for different complexities and apply to developers of different skill levels. The intuitive interface and guided interactive design greatly reduce the robot debugging threshold and improve programming efficiency.
DOBOT MG400 4-Axis Robotic Arm Specificasion:
Model | DT-MG-P4R07-01l | |
Number of Axes | 4 | |
Payload | 500 g (Max. 750 g) | |
Max. Reach | 440 mm | |
Repeatability | ±0.05 mm | |
Joint Ranges | J1 | ±160° |
J2 | -25°~85° | |
J3 | -25°~105° | |
J4 | ±180° | |
Joint Maximum Speed | J1 | 300° /s |
J2 | 300° /s | |
J3 | 300° /s | |
J4 | 300° /s | |
Power | 100~240 V AC, 50/60 Hz | |
Rated Voltage | 48V | |
Rated Power | 150W | |
Communication Mode | TCP/IP, Modbus TCP | |
Installation | Desktop | |
Weight | 8 kg | |
Base Size | 190 mm × 190 mm | |
Environment | 0 ℃~40 ℃ | |
Software | DobotStudio 2020,SCStudio |
