SeeedStudio reServer J2032 Host

reServer J2032 Host

reServer J2032 adopts a sleek form factor chassis design that packs it in an extremely compact form. This smart little server not only works easily and efficiently, it can also add artificial intelligence processing power to the formula. It is equipped with cutting-edge technology that can provide up to 21 TOPS to handle common AI tasks. It has a large amount of GPU RAM, one high speed, 2.5 Gigabit ethernet port and dual 1 gigabit ethernet ports, allowing for parallel multi-neural network operation. It has dual SATA III 6.0Gb/s data connectors, so it can equip up to two 3.5""/2.5"" SATA internal hard disk drives to get more storage. It also supports hybrid connectivity including 5G, LoRa®, BLE and WiFi.

reServer J2032 Scope of application:

• AI-enabled NVR(Network Video Recorder)
• Intelligent Video Analysis
• AMR
• Logistics Automation

reServer J2032 Techincal Specification:

• Modul: reServer J2032
• Artificial Intelligence Performance: 21
• GPU: NVIDIA Volta Architecture with 384 NVIDIA CUDA® Cores and 48 Tensor Cores
• Processor: 6-core NVIDIA Carmel ARM®v8.2 64-bit CPU 6 MB L2 + 4 MB L3
• DL Accelerator: NVIDIA Engines
• Video Accelerator: 7-Way VLIW Image Processor
• Memory: 8GB 128-bit LPDDR4x @ 51.2GB/s
• Storage: 16GB eMMC 5.1
• HDMI Interface: HDMI 2.0
• DisplayPort Interface: DP1.4
• DC Jack Power Interface: DC 12V @5A, 2.5mm middle pin
• Giga Ethernet:
  • rx: 2,35 Gbit/sn
  • tx: 1,4 ~ 1,6 Gbit/sn
  • 1000M Ethernet Port
