Sixfab Pico LTE Development Card

Sixfab Pico LTE Development Board

The Sixfab Pico LTE Development Board offers a unique solution for IoT (Internet of Things) projects. This compact board combines ultra-fast LTE connectivity with low power consumption and high performance, making it easy to connect your projects to the internet. Notable for its industrial suitability, this board also stands out for its small size.

The Pico LTE Development Board sets itself apart with extended compatibility features. It can seamlessly integrate with widely used development boards like Raspberry Pi and Jetson Nano. This allows you to quickly transition your projects from the prototyping phase to production.

With its high-performance LTE connection, you can achieve fast and reliable data transmission. Additionally, its low power consumption enhances energy efficiency, providing the possibility of extended use.

Technical Specifications for Sixfab Pico LTE Development Board:

• Communication: LTE Cat-4, 3G, 2G
• Frequencies: 4G: B3, B7, B20, B28; 3G: B1, B8; 2G: B3, B8
• Data Speed: 150 Mbps download, 50 Mbps upload (LTE)
• Antenna Connection: 2 SMA female connectors
• Interfaces: USB 2.0, UART, I2C, GPIO
• Supported Boards: Raspberry Pi, Jetson Nano
• Dimensions: 56 mm x 42 mm x 24 mm
• Power: 5V DC
• Operating Temperature: -40°C to +85°C
• Supported Operating Systems: Raspbian, Ubuntu, other Linux distributions
