xTool F1 Ultra

xTool F1 Ultra

xTool F1 Ultra is a professional laser engraving and marking machine that delivers high performance despite its portable design. With its 20W fiber laser, it provides fast and precise results on metals, plastics, leather, and many other materials.Its compact structure makes it perfect for desktop use and easy to transport wherever you need. With automatic focusing, high speed, and detailed processing capabilities, it’s ideal for everything from personal projects to small-scale production. Powerful. Fast. Portable. xTool F1 Ultra is the perfect choice for stepping into the world of professional laser marking.

Processing Capacity:

• Laser Type: 20W Diode Laser + 20W Fiber Laser

Processing Mode:

• Laser Engraving
• Laser Cutting

Supported Materials:

• Laser Cuttable, Diode Laser: Paper, Wood, Leather, MDF, Felt, Some dark opaque acrylic
• Laser Cuttable, Fiber Laser: Brass, Stainless Steel, Aluminum
• Laser Engravable, Diode Laser: Paper, Wood, Leather, MDF, Stainless steel, Some dark opaque acrylic, Bamboo, Fabric, Dark glass, Ceramic, Jade, Marble, Shale, Cement, Brick, Plated metal, Painted metal
• Laser Engravable, Fiber Laser: Stainless Steel, Aluminum, Brass, Sliver, Plastic, Platinum, Titanium, Gold

Working Area:

• 8,6" × 8,6" (220 mm × 220 mm)
• 8,6" × 19,6" (with conveyor) (220 mm × 500 mm)
• Max. Working Speed: 10000mm/s
• Max. Laser Cutting Capacity (Basswood): 15 mm in Multiple Passes
• Max. Laser Cutting Capacity (Acrylic): 12 mm in Multiple Passes
• Max. Processing Height: 145 mm
• Max. Rotary Engraving Diameter: 145 mm

Smart Software:

• Supported Software: xTool Creative Space/Lightburn

• Operating System: Android/IOS/iPad/macOS/Windows

• Connection Method: USB/Wi-Fi/IP/Hotspot

• Supported Files: SVG/DXF/JPG/JPEG/PNG/BMP/TIF

• Almake Compatibility: Yes

Easy Operation:

• Pre-assembled: Yes
• Built-in Camera: 16 MP Smart Camera
• Positioning Method: Camera Positioning
• Focus Mode: Autofocus
• Preview Method:
• Smart Camera Preview
• High-speed Light Live Preview

Accuracy & Precision

• Laser Spot Size:
• 0.08*0.1mm (20W Diode Laser)
• 0.03*0.03mm (20W Fiber Laser)
• Positioning Precision: N/A
• Ranging Precision: 0,5 mm, Camera
• Image Resolution: N/A
• Motion Accuracy: 0,00482 mm

General Information:

• Safety Certification: Class 4 Laser Safety
• Product Size: 10,75" x 14,69" x 19,37" (273 mm × 373 mm × 492 mm)
• Product Weight: 32,4 lb (14,7 kg)
• Max. Machine Input Power: 250 W - 275 W
• Power Adapter Input Voltage: 100 V - 240 V, AC 50/60 Hz
