Odyssey X86J4125864 Development Card V2 - 64GB EMMC - Linux Based and RP2040 processor

ODYSSEY - X86J4125864 v2 - with 64GB eMMC, Linux and RP2040 Core

ODYSSEY - X86J4125864 V2 has one coprocessor, quad-core Intel® Celeron® J4125 and RP2040. It is a development board equipped with multiple wireless connections along with dual 2.5 GbE interfaces. It has adequate storage capacity, equipment expandability, and fan heat dissipation, along with supporting 4K output. It can be run with multiple operating systems. Plus, all of these features make it ideal for use in a mini PC, a functional router, a media center, or other development applications. This card also supports 4G LTE communication, where you can insert a Micro-SIM card and insert a 4G module. With advanced interconnection, this small box can implement the function of a high-speed router and IoT gateway. It can be used in many areas such as NAS, Edge Computing, Robotics, Industrial Applications, Educational Fields.

ODYSSEY - X86J4125864 V2 Technical Specifications:

• Processor: Intel® Celeron® J4125 (Frequency: 2.0 - 2.7 GHz)
• Co-Processor: Raspberry Pi ® RP2040 32bit ARM® Dual Core Cortex® M0+
• Graphics: Intel® UHD Graphics 600 (Frequency: 250 – 750MHz)
• Memory: LPDDR4 8GB
• Wireless: Wi-Fi 802.11 a/b/g/n/ac @ 2.4/5 GHz HT160
• Networking:Intel® I226-V PCIe Gigabit LAN, Wake-On-LAN / PXE
• USB: USB 2.0 Type-A x2, USB 3.1 Type-A x1, USB 3.1 Type-C x1
• Video Interfaces: HDMI 2.0: Up to 4096x2160 @ 60Hz 24bpp
• RTC: JST 1.0 CR2032 3V
• TPM: fTPM (2.0)
• Power: DC Jack 5.5/2.1 mm / Type-C PD / DC Jack input: 12-19V DC / Type-C input: 15V DC
• Audio: Microphone + Headphone Combo Connector
• Expansion Slots: M.2(Key B, 2242/2280): SATA III, USB2.0, UIM; M.2 (Key M, 2242/2280): PCIe 2.0 ×4; Micro SD card Socket; SIM Card Socket; SATA III
• Size: 110 x 110 mm
• Operating Temperature: 0°C / 75°C
