Brand
:
Orange Pi
Product Code
:
22281
İşlemci
:
Cortex-A76 Cortex-A53 Bağlantı Noktası
:
1xUSB3.0/2xUSB2.0/Type C Kablosuz Bağlantı
:
Var Hafıza
:
8GB Out Of Stock
Notify me when its in stockSoC | Rockchip RK3588S (8nm LP process) |
CPU | • 8-core 64-bit processor • Big.Little Architecture: 4xCortex-A76 and 4xCortex-A55, Big core cluster is 2.4GHz, and Little core cluster is 1.8GHz frequency. |
GPU | • Arm Mali-G610 MP4 “Odin” GPU • Compatible with OpenGL ES1.1/2.0/3.2, OpenCL 2.2 and Vulkan 1.2 • 3D graphics engine and 2D graphics engine |
NPU | Built-in AI accelerator NPU with up to 6 TOPS, supports INT4/INT8/INT16 mixed operation |
PMU | RK806-1 |
RAM | 4GB/8GB/16GB /32GB(LPDDR4/4x) |
Memory | • QSPI Nor FLASH 16MB • MicroSD (TF) Card Slot • M.2 M-KEY Socket |
USB | USB3.0 × 1 USB2.0 × 2 Type-C (USB3.1) ×1 |
Video Output | • HDMI2.1, up to 8K @60Hz • DP1.4 (DisplayPort), DP1.4 and USB3.1 ports are multiplexed, and the port is shared with Type-C • 2 * MIPI D-PHY TX 4Lane, configurable up to 4K @60Hz |
Camera | • MIPI CSI 4Lane • 2 * MIPI D-PHY RX 4Lane |
Audio | CODEC: ES8388 • 3.5mm headphone jack audio input/output • Input: Onboard MIC • HDMI 2.1 eARC |
Ethernet | 10/100/1000Mbps Ethernet |
Expansion Port | For extending UART, PWM, I2C, SPI, CAN and GPIO interfaces. |
M.2 M-KEY Socket Expansion Slot | Support PCIe NVMe SSD Support custom PCIe Wi-Fi6+BT5.0 module |
Button | 1×MaskROM key 1×Recovery key 1×On/Off key |
Power Source | Support Type-C power supply, 5V @ 4A |
LED | Power indicator: red Status indicator: green |
Debugging | 3 Pin debug serial port (UART) |
Supported OS | Orangepi OS(Droid)、Orangepi OS(Arch)、Ubuntu、Debian、Android12 |
Dimension | 62mm*100mm |
Weight | 46g |
