YIHUA 852D+SE DIAPHRAGM PUMP REWORK STATION

YIHUA 852D+SE DIAPHRAGM PUMP REWORK STATION

YIHUA 852D is a soldering station specially designed for professionals and produced for advanced soldering work. With its multi-functional soldering iron, it can see all your works together. There are various modes and options for you to adjust on our product.

Two-in-one hot air gun and soldering iron, double LED digital display, stylishly compact,feature-rich, space-saving, and low shipping costs.LED temperature display, more accurate temperature control,more stable temperature and more vivid operation.Fine control diaphragm pump is employed for powerful airflows; the smaller the nozzle of the gun, the stronger the airflow. A cutting-edge ceramic-framed heating core for extremely stable and reliable performance!

• Rated voltage : AC 220V±10% 50Hz
• power : 700W±10％（Max）
• Working environment : 0～40℃ relative humidity＜80％
• Storage environment : 20～80℃ relative humidity＜80％
• Dimensions : 33 * 27 * 20.cm
• Weight : 5.11KG

Parts Parameters

Hot Air Gun:

• Operating Voltage : AC 220V±10% 50Hz
• Output power : 650W
• Temperature range : 100℃～500℃
• Air Supply Mode : Diaphragm pump
• Air Flow : 28L/min(MAX)
• Temperature Stability : ±15℃ （Static）
• Display Mode : LCD display
• PID Temperature Calibration Cycle : rapidly 20ms
• Heating Core : Ceramic columned heating element.

Soldering Iron:

• Operating Voltage : AC 26V±10% 50Hz
• Output power : 65W
• Temperature range : 200℃～500℃
• Temperature Stability : ±10℃ （Static）
• Display Mode : LCD display
• PID Temperature Calibration Cycle : high-speed 100ms
• Heating Core : Imported heater
