Soil Hygrometer Moisture Detection - Moisture Monitoring Module - Automatic Watering Device Garden Sensor - 12V

Brand
Robotistan
Product Code
20079
Ölçüm Parametresi
Nem
Ölçüm Aralığı
% 20-99Rh
Çalışma Voltajı
5V/DC
Fiyat
: 70.79 TL + VAT
KDV Dahil Fiyat
: 84.95 TL

Soil Hygrometer Moisture Detection - Moisture Monitoring Module - Automatic Watering Device Garden Sensor - 12V

Soil Hygrometer Moisture Detection - Moisture Monitoring Module is a module used to measure soil moisture. With this module, you can control the water requirement level of your plants by measuring the moisture of the soil in your pots, garden and greenhouse. You can help remember to water your plants by setting up an alarm system with a small buzzer, and you can also do this automatically using a water pump.

Soil Hygrometer Moisture Detection - Moisture Monitoring Module Pin Diagram:


Soil Hygrometer Moisture Detection - Moisture Monitoring Module Technical Specifications:

  • Module Input Voltage: 5V/DC
  • Output Type: Relay
  • Relay Trigger Voltage: 12V/DC
  • Relay Operating Voltage: 220V/AC (Max.)
  • Relay Carrying Current: 10A (Max.)
  • Humidity Measurement Range: 20-99%Rh
  • Control Sensitivity: %1RH
  • Indicator Lights: Yes

Soil Hygrometer Moisture Detection - Moisture Monitoring Module Dimensions:


Soil Hygrometer Moisture Detection - How Moisture Monitoring Module Works?

The Soil Hygrometer Moisture Detection - Moisture Monitoring Module has 2 probes, one of which is the positive side and the other is the negative side. An electric current flows through the ground between the two probes and encounters a resistance as it passes. This resistance is calculated with certain mathematical operations and the moisture in the soil is measured. This process requires 12V and this voltage can damage the Arduino, so a relay module is put between the Arduino and the module. (Relay module is included in the package content).

Soil Hygrometer Moisture Detection - Moisture Monitoring Module Package Contents:

  • Soil Hygrometer Moisture Detection - Moisture Monitoring Module
  • 12V Relay Module
  • 2xFemale-Female Jumper Cable
