This DC-DC step-up boost voltage regulator board has XL6009, a step-up switching regulator, on it. The regulator can pass through current up to 4A on itself. It's input voltage range is 3-32V and you can get an output voltage adjustable between 5-35V via the trimpot on the board. You can use this voltage regulator board in hobby and robotic projects.
When using this board, the input voltage always must be lower than outtput voltage. IN+ is positive voltage input, IN- is GND input, OUT+ is positive voltage output, OUT- is GND output.
Features:
- Input Voltage: 3-32V
- Output Voltage: 5-35V
- Output Current: 4A
- PCB Size: 43x21mm
