Temperature controlled relay module
You can use this module to turn on or off appliances according to the temperature. Works with 12VDC.
Adjustable Digital Thermostat Module Technical Specs:
- Temperature measuring range: -50 °C to 110 °C
- Resolution: -9.9-99.9 at the temperature of 0.1 °C and other temperature range of 1 °C
- Measurement accuracy: + 0.1 °C
- Control accuracy: 0.1 °C
- Return difference accuracy: 0.1 °C
- Refresh rate: 0.5S
- High temperature protection: 0-110 °C
- Input voltage: DC12V
- Measurement input: NTC (10K0.5%) waterproof sensor
- Output: all the way 20A relay
- Environmental requirements: -10 °C – 60 °C humidity 20%–85%
- Size: 48mm (L) * width 29mm* depth: 32mm
- Hole size: 46*26.5mm
- Power consumption: the quiescent current is less than or equal to 35MA operating current: less than 65MA
- Power supply: 12V200MA
