Raspberry Pi Pico

Raspberry Pi Pico

Raspberry Pi Pico is a microcontroller that you can use in your embedded systems projects and prototyping. Raspberry Pi Pico, powered by the RP2040 microcontroller, has a dual-core ARM Cortex M0 + processor. The low-cost Raspberry Pi Pico stands out with its low power consumption and high performance. Raspberry Pi Pico, which can be programmed with both C / C ++ and MicroPython, appeals to users of all ages.

Technical Specifications:

• Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz
• 264KB of SRAM, and 2MB of on-board Flash memory
• Castellated module allows soldering direct to carrier boards
• USB 1.1 with device and host support
• Low-power sleep and dormant modes
• Drag-and-drop programming using mass storage over USB
• 26 × multi-function GPIO pins
• 2 × SPI, 2 × I2C, 2 × UART, 3 × 12-bit ADC, 16 × controllable PWM channels
• Accurate clock and timer on-chip
• Temperature sensor
• Accelerated floating-point libraries on-chip
• 8 × Programmable I/O (PIO) state machines for custom peripheral support

Useful Links:

• Raspberry Pi Pico Datasheet
• Raspberry Pi Pico Pinout
• RP2040 Datasheet
• Hardware Design with RP2040
• Raspberry Pi Pico C/C++ SDK
• Raspberry Pi Pico Python SDK
